Discoid lateral meniscus

Applied Radiology — Vol. 37 , Issue 3 , pp. 30 -32

DOI: 10.37549/AR1596

Published: March 1, 2008

Ari Youderian, MD, Margaret A. Stull, MD, Samuel Chmell, MD

Categories

article Article ar

CASE SUMMARY

This 19-year-old woman had a 12-month history of generalized right knee pain, which developed after starting a new job that required extensive standing. The patient denied any prior knee pain or trauma. She had occasional locking of her knee during flexion and when crossing her legs. On physical examination, lateral popping was palpable with motion. Her medical history was otherwise unremarkable.

Advertisement

IMAGING FINDINGS

Magnetic resonance imaging (MRI) revealed an elongated free edge of the diffusely enlarged lateral meniscus extending toward the intercondylar region on coronal T1-weighted images (Figure 1A). Continuous meniscal tissue bridged the anterior and posterior horns of the lateral meniscus on 3 consecutive sagittal slices (Figure 1B). The intrameniscal signal in the anterior horn was compatible with mucinous degeneration.

FIGURE 1.
FIGURE 1. (A) A central coronal T1-weighted image (repetition time [TR] 500, echo time [TE] 9) obtained on a 1.5T Signa MR system (GE Healthcare, Waukesha, WI) shows increased transverse width of the lateral meniscus (arrow), which is significantly larger than the medial meniscus. (B) A sagittal fast spin-echo proton-density–weighted image (TR 3000, TE 12) shows the continuity of the anterior and posterior meniscal horns. The anterior horn is abnormally larger than the posterior horn. Mucinous degeneration in the anterior horn is also seen (arrow).

Advertisement

DIAGNOSIS

Discoid lateral meniscus

Advertisement

DISCUSSION

Discoid lateral meniscus is a congenital condition that is estimated to occur in 4% to 5% of the population1-4 but has been shown to be as high as 13% in Asian populations.5 It is the most common abnormal meniscal variant in children.6 The condition is typically asymptomatic and, therefore, is infrequently diagnosed.7 The most frequent symptom is pain that usually begins with a minor trauma. Other symptoms include clicking, snapping, clunking, and locking during movement, as well as joint-line tenderness, reduced mobility, and “giving-way”6,8,9 A high percentage of cases present with an associated meniscal tear and peripheral rim instability.4,9,10 Although discoid lateral meniscus is commonly bilateral, symptoms tend to occur on one side.8

Discoid lateral meniscus is traditionally classified as one of 3 types based on those described by Watanabe et al.11 The complete type refers to complete meniscal coverage of the tibial plateau, while the incomplete type covers <80% of the tibial plateau. The Wrisberg ligament type refers to a more normal morphology, except for a thick posterior horn and a lack of posterolateral meniscotibial attachment, and has a thick posterior tibial attachment.2,3,6 Newer classifications based on shape, stability, tear pattern, and symptoms have been proposed because classification and surgical outcomes have been associated with meniscal tear patterns and lateral compartment changes.12,13

The etiology of discoid lateral meniscus is still debatable, although opinions in the literature tend toward a congenital origin. The reports of additional anatomic variations complicate the original etiology theories and support the concept that discoid lateral meniscus may be due to multiple etiologies.

The most prominent distinguishing features of discoid lateral meniscus on plain radiographs include widening of the lateral joint space and a high fibular head.12,14,15 Additionally, marginal osteophytes and cupping or flattening of the lateral tibial plateau may be revealed.15 MRI has been shown to be effective in the diagnosis of discoid lateral meniscus. Any of the following factors have been shown to be specific for diagnosis: 1) 14- to 15-mm minimum transverse width of the lateral meniscus on a central coronal image. Normally, the meniscus measures 5 to 13 mm; 2) ≥20% for the ratio of the meniscus to the tibia; and 3) ≥75% for the ratio of the sum of the width of the anterior and posterior horns to the meniscal diameter on a sagittal slice that shows a maximum meniscal diameter. Contiguous body segment appearance must be shown on ≥3 consecutive sagittal 4- to 5-mm thick slices.16,17 MRI may also help identify specific types of meniscal tears.18

The most commonly practiced treatment for stable, complete, or incomplete types of discoid lateral meniscus is partial meniscal excision. In this case, our patient underwent surgical excision, leaving a 6- to 7-mm peripheral rim circumferentially, anteriorly, and posteriorly. Postsurgically, the patient continued to have pain and decreased extension of the knee. She had to undergo a second knee arthroscopy to remove more of the meniscus and remaining scar tissue. The patient is now doing well and currently reports no pain or limitation in movement.

CONCLUSION

The diagnosis of discoid lateral meniscus is easily rendered on MRI. Invasive surgical treatment for discoid lateral meniscus is effective for symptomatic relief but is recommended only if the symptoms of the condition become significantly problematic.

References

  1. Dickhaut S, DeLee J. The discoid lateral-meniscus syndrome. J Bone Joint Surg Am. 1982;64:1068-1073.
  2. Kocher M, Klingele K, Rassman S. Meniscal disorders: Normal, discoid, and cysts. Orthop Clin North Am. 2003;34:329-340.
  3. Neuschwander D, Drez D, Finney T. Lateral meniscal variant with absence of the posterior coronary ligament. J Bone Joint Surg Am. 1992;74:1186-1190.
  4. Rohren E, Kosarek F, Helms C. Discoid lateral meniscus and the frequency of meniscal tears. Skeletal Radiol. 2001;30:316-320.
  5. Fukuta S, Masaki K, Korai F. Prevalence of abnormal findings in magnetic resonance images of asymptomatic knees. J Orthop Sci. 2002;7:287-291.
  6. Kelly B, Green D. Discoid lateral meniscus in children. Curr Opin Pediatr. 2002;14:54-61.
  7. Davidson D, Letts M, Glasgow R. Discoid meniscus in children: Treatment and outcome. Can J Surg. 2003;46:350-358.
  8. Connolly B, Babyn P, Wright J, Thorner P. Discoid meniscus in children: Magnetic resonance imaging characteristics. Can Assoc Radiol J. 1996;47:347-354.
  9. Rao P, Rao S, Paul R. Clinical, radiologic, and arthroscopic assessment of discoid lateral meniscus. Arthroscopy. 2001;17:275-277.
  10. Klingele K, Kocher M, Hresko M. Discoid lateral meniscus: Prevalence of peripheral rim instability. J Pediatr Orthop. 2004;24:79-82.
  11. Watanabe M, Takada S, Ikeuchi H. Atlas of Arthroscopy. 1969.
  12. Asik M, Sen C, Taser O. Discoid lateral meniscus: Diagnosis and results of arthroscopic treatment. Knee Surg Sports Traumatol Arthrosc. 2003;11:99-104.
  13. Bin S, Kim J, Kim J. Correlation between type of discoid lateral menisci and tear pattern. Knee Surg Sports Traumatol Arthrosc. 2002;10:218-222.
  14. Kim S, Moon S, Shin S. Radiographic knee dimensions in discoid lateral meniscus: Comparison with normal control. Arthroscopy. 2000;16:511-516.
  15. Nawata K, Teshima R, Ohno M. Discoid lateral menisci in older patients. A radiographic study of 21 cases. Int Orthop. 1999;23:232-235.
  16. Araki Y, Yamamoto H, Nakamura H, Tsukaguchi I. MR diagnosis of discoid lateral menisci of the knee. Eur J Radiol. 1994;18:92-95.
  17. Samoto N, Kozuma M, Tokuhisa T, Kobayashi K. Diagnosis of discoid lateral meniscus of the knee on MR imaging. Magn Reson Imaging. 2002;20:59-64.
  18. Chiang H, Jiang C. Discoid lateral meniscus: Clinical manifestations and arthroscopic treatment. J Formos Med Assoc. 2003;102:17-22.

Citation

Youderian A, Stull MA, Chmell S. Discoid lateral meniscus. Applied Radiology. 2008;37(3):30-32. doi:10.37549/AR1596.
