CASE SUMMARY

A 49-year-old female patient presented with hypertension and underwent a vascular workup with a combination of magnetic resonance angiography (MRA) and computed tomography angiography (CTA) studies.

Advertisement

DISCUSSION

Fibromuscular dysplasia (FMD) is an autosomal dominant inherited disorder characterized by fibrous thickening of the intima, media, or adventitia of the artery. The renal and carotid arteries are most commonly involved. Less often, vertebral, visceral, and extremity artery involvement is seen. More than one artery may have evidence of FMD in 28% of people with this disease. FMD may affect up to 5% of the population (found in close to 4% of normal renal donors). FMD is associated with stenosis-related renovascular hypertension. Symptoms of craniocervical involvement include headaches, pulsatile tinnitus, and light headedness, although patients are often asymptomatic. FMD is often diagnosed incidentally in the absence of any signs or symptoms during an imaging study. Vascular lesions include stenosis, aneurysm, and dissection. Narrowed vessels show a characteristic “string of beads” appearance.

Note the “string of beads” narrowed appearance of the renal arteries (worse on the right) as well as the celiac axis. There is an aneurysm of the superior mesenteric artery.
Note the abnormal appearance of the distal right-internal carotid artery with apparent widening on the whole volume maximum intensity projection (MIP) images. The axial-source images reveal clear evidence of a dissection.
Note the striking beadlike narrowing of both internal carotid arteries. There is subtle distal vertebral involvement on both sides.

References

  1. Slovut D, Olin J. Fibromuscular dysplasia. N Engl J Med. 2004;350:1862-1871.
