Editor’s note: This is the first part of a two-part series. The second part will appear in the March/April 2023 issue of Applied Radiology.

Most diagnostic errors by radiologists in clinical practice involve musculoskeletal findings on radiographs, and missed fractures represent more than 90% of malpractice claims.1,2

Knee radiography is one of the most common musculoskeletal studies interpreted by radiologists in daily clinical practice and is the standard of care for initial imaging of acute or chronic knee pathology.3-5 A variety of knee radiography protocols exist, but every study should at minimum contain frontal (anteroposterior [AP] or posteroanterior) and lateral views.4 Other common options in a knee radiograph series include weight-bearing, patellar tangential, oblique, and cross-table lateral views.4,6,7

In this article we describe worrisome imaging signs on knee radiographs to inform radiologists and radiologists-in-training how to identify a select group of difficult-to-diagnose traumatic pathologies and when to recommend additional imaging or clinical work up. We also discuss incidental signs of degenerative joint disease and a developmental anomaly on knee radiographs that mimics worrisome pathology, in order to allow definitive diagnosis and to bestow confidence that no further work up is required.

Traumatic Fractures

Segond Fracture

The Segond fracture is important to recognize due to its strong association with anterior cruciate ligament (ACL) and meniscal tears.8 The typical mechanism involves excessive internal rotation and varus stress, which cause a focal avulsion of bone from the lateral tibial plateau, commonly sustained as a sports-related injury. Patients commonly present with acute knee pain.9

On radiographs, the Segond fracture appears as a small, avulsed bone fragment from the lateral tibial plateau (Figure 1). Although the injury is subtle in appearance on radiographs, magnetic resonance imaging (MRI) demonstrates the strong association with ACL tear to greater detail).7 The primary emphasis is placed on surgical intervention for the underlying knee internal derangement.10

Figure 1
Figure 1 Segond fracture. (A) AP radiograph shows a mildly displaced acute fracture fragment (arrow) from the lateral aspect of the lateral tibial plateau in a patient presenting with acute knee trauma. (B) Sagittal T2 fat-saturated MRI shows an absence of the anterior cruciate ligament at the intracondylar notch (arrows) compatible with complete tear.

Tibial Spine Fracture

Tibial spine fractures most often occur in skeletally immature knees. This injury is considered equivalent to adult ACL tears, as children and adolescents have a greater propensity to suffer acute bone injury from ACL avulsion of the tibial spines rather than ligamentous tear of the ACL as compared to adults.11 Mechanisms for injury include abnormal knee rotation or blunt trauma near the anterior knee while the joint is flexed. Patients typically present with pain, swelling, and decreased range of motion.12

Tibial spine fractures appear through the central region of the proximal tibia epiphysis, often with an associated knee joint effusion (Figure 2). Computed tomography (CT) and MRI have greater sensitivity to delineate fracture characteristics, while MRI can also be used to diagnosis additional meniscal, ligamentous, and/or articular cartilage internal derangements relevant for preoperative planning.11 Treatment of these fractures with ACL avulsion typically consists of surgery or casting in the pediatric population.11

Figure 2
Figure 2 Tibia spine fracture. (A) AP radiograph shows a mildly displaced transverse acute fracture at the tibial spine region (arrow) of the proximal tibial epiphysis in a skeletally immature patient. There is also a nonossifying fibroma incidentally noted at the distal femoral metadiaphysis. (B) Sagittal T1 and (C) sagittal T2 fat-saturated MR images show the anterior cruciate ligament (short arrow) attached to the avulsed tibial spine fracture (long arrow) with associated bone marrow edema.

Lipohemarthrosis

In the acutely traumatized knee, systematic evaluation of the soft tissues is required. Lipohemarthrosis, defined as intra-articular floating fat in a joint effusion, is an important clue for diagnosing radiographically-occult fractures.6,13 Traumatic intra-articular fracture is the primary mechanism for fatty marrow leakage into the joint space and lipohemarthrosis is pathognomonic for acute fracture.6,14 Acute pain and swelling are classic symptoms/signs.

Radiologists should consider cross-table lateral radiographs for all traumatic knee series, as standard frontal and lateral views are less likely to identify lipohemarthrosis.6,15 On cross-table lateral views, the key finding is a sharp linear interface between hydrophobic floating fat and hydrophilic hemarthrosis, most commonly seen at the suprapatellar pouch (Figure 3). Occasionally, lipohemarthrosis will present with three distinct layers when the hemarthrosis further separates into distinct serum and red blood cell layers.6,16 In the setting of lipohemarthrosis without a definite radiographically visible fracture, the radiologist should inform the exam requestor that additional cross-sectional imaging is indicated to detect and characterize the occult fracture.17 Treatment is typically driven by orthopedic management of the underlying fracture, with self-resolution of the lipohemarthrosis.

Figure 3
Figure 3 Lipohemarthrosis. (A) Cross-A B table lateral and (B) AP radiographs show no obvious fracture in a patient with blunt trauma to the knee after a fall. The sharp interface produced by the fat-fluid level (between arrows) reflects a lipohemarthrosis owing to an acute occult fracture, indicating the need for follow-up with cross-section imaging.

Advertisement

Traumatic Malalignment

Anterior tibial translation

Anterior tibial translation (ATT) is an important radiographic sign of knee instability.18 The ACL primarily resists ATT but when torn allows abnormal anterior subluxation of the tibia relative to the femur.19,20 In the acute clinical setting, severe pain and swelling are common. In cases of subacute clinical presentation, perceived instability may be the most pressing concern.21

On a lateral knee radiograph, ATT appears as the central region of the femoral condyles articulating with the posterior third of the proximal tibial plateau (Figure 4). In this setting, MRI may be considered to definitively characterize the ACL tear and identify other potential injuries. Treatment is based on orthopedic management of the tear and any other associated internal derangements.

Figure 4
Figure 4 Anterior tibial translation. (A) A B Lateral radiograph from a pedestrian struck by a car shows a suprapatellar knee effusion (black asterisk). The center of the femoral condyles (long arrow) articulates with the posterior third of the tibial plateau instead of the center (short arrow). (B) Sagittal T2 fatsaturated MR image shows an absence of the anterior cruciate ligament at the intracondylar notch (arrows) compatible with complete tear. An acute bone contusion is present at the tibia (white asterisk).

Patella Alta

Patella alta is a “high-riding” patella that rests in a more proximal position than expected relative to the tibiofemoral articulation. Most cases represent a developmental anomaly, but acquired patella alta is suspicious for a ruptured patellar tendon. Acutely acquired patella alta typically presents with new-onset knee pain, swelling, and decreased range of motion.22,23 Chronic patella alta presents with a more insidious onset of patellofemoral pain and recurrent patellar subluxation or dislocation.24,25

Patella alta is most commonly evaluated on the lateral knee radiograph using the Insall-Salvati method (Figure 5). Patella alta is diagnosed when the distance from the inferior pole of the patella to tibial tuberosity is more than 20% of the maximum oblique distance across the patella.26 Thus, a ratio of more than 1.2 indicates patella alta on a lateral knee radiograph. The condition is managed orthopedically on a case-by-case basis, depending on the underlying cause and presenting symptoms.27

Figure 5
Figure 5 Patella alta. (A) Lateral radiograph of a patient with acute blunt trauma from a fall shows a knee effusion (asterisk) and a > 20% difference (ratio > 1.2) between the maximum oblique distance across the patella (black line, 4.5 cm) and the distance from the patellar inferior pole to tibial tuberosity (white line, 7.0 cm). (B) Sagittal T1 MR image shows an acute patellar tendon tear (arrow).

Transient Patellar Dislocation

Transient patellar dislocation (TPD) is a knee instability syndrome affecting the patellofemoral compartment. The term “transient” implies brief events of lateral patellar subluxation or dislocation followed by spontaneous reduction.28,29 Although TPD may occur at any age, adolescents and young adults classically are most affected. Patients often present with knee pain and a history of patellar dislocation with spontaneous reduction. Clinically, TPD is elusive, and more than 50% of cases are initially clinically misdiagnosed.28

Radiographic diagnosis of TPD may be challenging, since most spontaneously reduce prior to imaging. A high clinical suspicion and correlation with clinical history increase the probability of diagnosing this abnormality. Detecting an osseous fragment in the suprapatellar joint space may provide the only perceptible clue (Figure 6). Most cases often present with a nonspecific joint effusion.30 MRI evaluation can “rule in” TPD, since the modality allows for identification of the classic “kissing contusion” bone marrow edema pattern located at the medial patellar pole and lateral femoral condyle (Figure 6). Corrective surgery to address predisposing ligamentous and osseous abnormalities is performed in knees deemed unstable.28,31

Figure 6
Figure 6 Transient patellar dislocation. (A) Sunrise radiograph of a patient with pain and instability shows a small ossific fragment (arrow) in the patellofemoral compartment. (B) Axial T2 fat saturated MR image shows the classic bone marrow contusion pattern centered at the medial patellar pole (short arrow) and lateral aspect of the lateral femoral condyle (long arrow), allowing for definitive diagnosis. An effusion is also present (asterisk).

Miscellaneous Worrisome Mimics

Advertisement

Osteochondritis dissecans

Osteochondritis dissecans (OD) is a chronic disease of subchondral bone that can mimic signs of fracture on knee radiographs, most commonly in the lateral region of the medial femoral condyle. Adolescents and young adults are the most likely to manifest OD, often presenting with knee pain, swelling, and locking.32 Identifying advanced-stage OD before the in-situ bone fragment displaces into the joint space improves long-term prognosis.

Radiographic findings of advanced OD with an in situ fragment demonstrates an ossific fragment at the articular surface, separated from the adjacent bone by a curvilinear lucency (Figure 7). Its location at the lateral region of the medial femoral condyle and relative smooth margins of the curvilinear lucency help to differentiate OD from an acute fracture. MRI can confirm the diagnosis and provide staging information critical for treatment. Patients with unstable in-situ fragments are candidates for surgery.32,33

Figure 7
Figure 7 Osteochondritis dissecans. (A) AP radiograph demonstrates a discrete curvilinear lucency (arrow) with an adjacent small, ovoid ossific fragment at the lateral aspect of the medial femoral condyle. (B) Coronal proton density and (C) sagittal short tau inversion recovery MR images demonstrate fluid signal (long arrow, B) completely separates the in-situ fragment (short arrow, C) from the medial femoral condyle.

Incidental Signs

Degenerative Joint Disease

Geode

A geode is a subchondral cyst typically associated with full-thickness articular cartilage loss. Geodes are not true “cysts” but instead represent cyst-like changes. Most cases do not represent a diagnostic dilemma for the radiologist, since they typically present with other findings related to osteoarthritis — including osteophytes, joint space loss, and/or subchondral sclerosis.34-36 Symptomatic patients often present with complaints emblematic of osteoarthritis — knee pain, stiffness, and swelling, among others. However, geodes presenting on radiographs in isolation without other definitive signs of osteoarthritis may be confused with more worrisome diagnoses such as malignancy.

Radiography demonstrates geodes as classically round, well-defined, lytic lesions with a thin, sclerotic, narrow zone of transition at an articular surface (Figure 8). Their location at the subchondral bone of an articular surface and appearance should allow for confident radiographic diagnosis of a benign, degenerative geode requiring no additional follow-up.

Figure 8
Figure 8 Geode. (A) Lateral view shows a small, round, linear lucency with a thin sclerotic margin (arrow) in the fibular head. Proximity to the proximal tibiofibular joint allows for the diagnosis of a benign geode. (B) Lateral view in a different patient shows an isolated focal lytic lesion with a narrow zone of transition at the articular surface of the patella (arrow) consistent with a geode.

Advertisement

Central Osteophyte

Osteoarthritis is commonly diagnosed in patients who present clinically with variable complaints of knee pain, swelling, locking, and stiffness. The osteophyte is a basic feature in establishing the radiographic diagnosis, with osteophyte formation typically occurring at the joint margins. The precise pathogenesis of osteophytes is still unclear but is thought to represent a response to altered biomechanics.37 Osteophytes that occur at the center, rather than at the margin, of the joint are much less common.38,39 Radiologists should not confuse central osteophytes with truly worrisome bone conditions.

On radiographs central osteophytes appear as well-defined focal osseous protuberances in continuity with the subchondral bone at the articular surface (Figure 9). Associated signs of osteoarthritis – marginal osteophytes, joint-space narrowing, and/or geodes — should increase diagnostic confidence for a degenerative central osteophyte requiring no additional work up.

Figure 9
Figure 9 Central osteophyte. (A) A B AP view in a patient with signs of degenerative joint space narrowing and small marginal osteophyte formation with a small osseous protuberance at the central articular surface of the lateral femoral condyle (arrow). (B) Coronal proton density MRI image shows an osseous protuberance (arrow) in continuity with the subchondral bone and without overlying articular cartilage, consistent with a central osteophyte.

Baker Cyst Osteochondral Body

Degenerative intra-articular osteochondral bodies (“loose bodies”) are a well-known condition in patients with knee osteoarthritis. On radiographs, a mineralized mass centered in the soft tissues rather than in the knee joint raises potential suspicion for malignancy. Baker cysts are synovial cysts created by a region of the posterior knee joint capsule that anatomically has displaced in a posterior direction between the semimembranosus and medial head of the gastrocnemius tendons. Typically, joint contents travel into the Baker cyst through a mechanism resembling a one-way valve.35 Displaced osteochondral bodies, and even meniscal fragments, are known to collect in Baker cysts.

Radiographically, single or multiple well-defined osteochondral bodies appear as one or more mineralized masses in the soft tissues behind the knee (Figure 10). Identifying additional findings associated with osteoarthritis — osteophytes, joint space loss, geodes, and/or subchondral sclerosis — should allow more confident diagnosis of degenerative osteochondral bodies in a Baker cyst without the need for follow up. Radiographs that lack any other signs of osteoarthritis, have an ill-defined or stippled pattern of mineralization, or show an unexplained mineralized soft-tissue mass in a location not consistent with a Baker cyst should undergo cross-sectional imaging to exclude malignancy or other worrisome conditions.35,40

Figure 10
Figure 10 Baker cyst osteochondral body. (A) Lateral radiograph shows an osteochondral body (arrow) with peripheral mineralization in the soft tissues of the posterior knee. (B) Axial proton density fat saturated MR image shows the osteochondral body located inside of a Baker cyst.

Miscellaneous (Incidental)

Multi-partite Patella

Developmental anomalies of the patella are common. The patella is the largest sesamoid bone in the body with variable fusion patterns of secondary ossification centers. The most common location is the superolateral pole.41,42 Particularly in the setting of trauma, multi-partite patella can create diagnostic uncertainty on radiographs by mimicking the appearance of acute fracture.

Multi-partite patella can be differentiated from a comminuted fracture by identifying two or more smooth, well-defined, and non-united round or ovoid secondary ossification centers located at the superolateral pole and separated from each other and the larger patellar body by well-defined curvilinear lucencies (Figure 11).41-43 In the absence of associated bony tenderness with direct palpation at the site of a classically-appearing multi-partite patella on physical examination, no follow up is necessary.

Figure 11
Figure 11 Multi-partite patella. AP radiograph shows two well-defined, non-united ossified secondary ossification centers at the superolateral pole of the patella, consistent with a tri-partite patella.

Conclusion

Knee radiography is common in daily clinical practice. Knowledge of worrisome signs related to difficult-to-detect traumatic knee pathology informs radiologists when to expeditiously recommend additional imaging and/or clinical evaluation.

Familiarity with less-common incidental signs of degenerative joint disease and developmental anomaly allow for definitive diagnosis and confidence that no further evaluation is required.
